中压2BK单级液环压缩机

单级液环压缩机

中压，2BK

气量50至2,400 SCFM（85至4,100 m3/h）

NASH 2BK单级液环压缩机系列具有负压和正压入口，特别适用于压力增加的应用。气量范围从50至2,400 SCFM（85至4,100 m3/h）2BK压缩机深得石油和天然气、石化和化学加工业中从事碳氢化合物压缩和回收工作者的信赖。

描述

专为腐蚀和不可预测的行业而设计

2BK压缩机系列为更苛刻的石油和天然气、石化和化工行业提供灵活的安装和性能。在诸如火炬气回收（FGR）、蒸汽回收和氯乙烯单体（VCM）回收等应用中，2BK是一种出色的单级压缩机。

从真空到压缩 - 经优化的性能

石油和天然气、石化和化工行业， 许多应用需要在某道工序中进行真空和压缩。2BK液环压缩机是功能强大的机器，具有负压和正压入口。该压缩机尤其适用于增加压力，靠一台机器即可提供所需压力。通过调整机体形状，2BK压缩机可根据运行条件优化。

技术数据

吸入流量：50至2,400 ACFM（85至4,100 m3/h）

排气压强范围：至75 psia（至6 bar abs.）

压差： 至75 psi（至5 bar）

轴密封：机械密封（单端/双端）

结构材料：不锈钢

Single Stage

Liquid Ring Compressor

Medium Pressure, 2BK

Capacity 50 to 2,400 SCFM (85 to 4,100 m3/h)

The NASH 2BK single stage liquid ring compressor series functions with both negative and positive pressure inlets, and are/is particularly suitable for increased pressures. With capacity ranging from 50 to 2,400 SCFM (85 to 4,100 m3/h) the 2BK compressors are relied on for the compression and recovery of hydrocarbons in the oil & gas, petrochemical, and chemical process industries.

Description

Designed for Abrasive and Unpredictable Industries

The 2BK compressor series offers flexible installation and performance for the most demanding oil & gas, petrochemical, and chemical process industries. In applications such as Flare Gas Recovery (FGR), Vapor Recovery, and vinyl chloride monomer (VCM) recovery the 2BK is a standout single stage compressor.

From Vacuum to Compression - Optimized Performance

In the oil & gas, petrochemical, and chemical process industries, many applications require vacuum and compression in one process. The 2BK liquid ring compressor is a robust machine functioning with negative and positive pressure inlets. This compressor is particularly suitable for increased pressures, providing the required pressure in one machine. Through engineered adjustments to the body shape, the 2BK compressor can be optimized per operating conditions.

Technical Data

2BK Capacity Chart

Suction Capacity: 50 to 2,400 SCFM (85 to 4,100 m3/h)

Discharge Pressure Range: to 75 psig (to 6 bar abs.)

Differential Pressure: to 75 psi (to 6 bar)

Shaft Seals: Mechanical Seals (single acting/ double acting)

Materials of Construction: Stainless Steel
